Galil is excited to announce the release of the new D3643 drive, which is now available for the DMC-40x0 and DMC-41x3 series of motion controllers. Based on the existing D3640 drive which is designed to run 3-phase brushless motors, the D3643 is specifically designed to run brushed motors creating a more economical solution. Both the D3643 and D3640 are linear amplifiers which
means there is no switching of the power transistors. This results in smooth, ripple free motion, and high precision positioning. Linear amplifiers also generate very little electromagnetic interference (EMI).
The D3643 offers great performance for low inductance brushed motors as well as voice coil motors. The D3643 can drive 4 motors independently, at up to 1 Amp continuous and 2 Amps peak current per channel. Its voltage range is a single supply 15-40 VDC. All linear amplifiers will typically operate with far less efficiency than switching amplifiers resulting in higher heat generation. For applications requiring higher current, Galil has multiple pulse width modulation (PWM) amplifier options available. Galil can also create custom OEM solutions based on customer requirements.
Contact support@galil.com and our applications engineer can help select the optimal drive solution.
Figure 1: UL 61800 Certificate
Following products have been UL Listed:
(UL 61010)
RIO-47100
RIO-47120
RIO-47142
RIO-47162
DMC-42x0
Figure 2: UL 61010 Certificate
